SLIMLINE LFP12.8V 100Ah 12V Lithium Battery Pack For Marine Boat
Sailboat
PERFORMANCE
SLIMLINE 100 sampling lithium iron phosphate battery cell, with
built-in intelligent BMS, has characteristics such as long service
life, light weight, high discharge current, wide temperature range,
fast charging, maintenance free, safety and environmental
protection.At the same time, it has multiple charging and
discharging interfaces,supporting three charging methods: car
generator,photovoltaic panel, and city power. lt is a multi-
functional power supply, making it easier to use and more
convenient.
CONNECTOR
INPUT
Anderson 50A(blue) Alternator,DC10.5-DC16.5V Max40A
Anderson 50A (red) Solar,DC9-DC50V Max40A
OUTPUT
Anderson 175A (grey) DC10V-DC14.6V,Max150A
Anderson 50A (grey)*2 DC10V-DC14.6V,Max50A
Car cigarette lighter DC10V-DC14.6V,Max10A
American standard refrigerator socket DC10V-DC14.6V,Max10A
USB-A QC3.0(x2) 5V-3A;9V-2A;12V-1.5A,Max18W
USB-C PD3.0 5V-3A:9V-3A:12V-3A;15V-3A;20V-3A,Max60W
OTHER
4P Wiring terminal Display interface
2P Wiring terminal IGNITION
| BATTERY DATA SHEET |
| Electrical Parameters | | Mechanical Parameters |
| Nominal Voltage | 12.8V | Dimension(W×H×D)
Including installation feet | 685x230x50mm |
| Rated Capacity | 110Ah | 26.97 x9.06x 1.97'' |
| Energy | 1408Wh | Weight | 15kg |
| Resistance | ≤30mΩ | Terminal Type | Reference connector
parameters |
| Efficiency | ≥0.98 | Battery Housing | SPCC |
| Cycle Life | >3000cycles @1C,80% DOD | Housing Protection | IP30 |
| Self Discharge | ＜ 5% per Month | Cell Type-Chemistry | LiFePO4 Cell |
| Cell in Series/Parallel | 4S/1P | Communication | Bluetooth |
|
| Discharge Parameters | | Charge Parameters |
| Continuous Discharge Current | 100A | Charge Method | CC-CV |
| Pulse Discharge Current | 200A (<1S) | Charge Voltage | 14.2~14.6V |
| Recommended Volt. Disconnect | 10V | Recommended Float Voltage | 13.3~13.4V@100% |
| BMS Discharge Cut-off Voltage | 10V | Recommended Charge Current | 55A |
| Reconnect Voltage | 10.8V | Maximum Charge Current | 100A |
| Short Circuit Protection | 300-800us | BMS Charge Cut-off Voltage | 14.8V |
